SimpleIndustry Precise External Temperature Hot

Portfolio Image

Project Description

Device Specifications:

  • Dimensions: 94 x 65 x 32,5 mm (without holder)
  • Volume: 105 cm3
  • Weight: 66 g
  • Color: Red
  • Recommended operating temperature: -20°C to 105°C
  • Waterproof rating: IP68
  • Fixtures for screws drill in and high tensile cable ties:  Horizontal mounting (vertical or magnet upon request)
  • End customer packaging: Optional, several ready options
  • Branding: Optional, several ready options

SENSORS:

  • Button: No
  • LED: No
  • Accelerometer: Yes
  • Vibration detection and recording: Yes
  • Inclination detection: Yes
  • Shock detection: Yes
  • WiFi sniffing for tracking: Yes
  • Ambient temperature:  Yes , +-3°C
  • Precise temperature: Yes, +-0,5°C
  • Humidity: No
  • Recording and redundant reporting of events: Yes
  • Magnetometer for door opening: No
  • Reed switch for door opening and status: Yes
  • Reed switch recording and counting: Yes
  • Ambient light detection: Yes
  • Machine learning / AI:  No
  • Barometer: No
  • Gyroscope: No
  • Pedometer: No
  • Precise time: No
  • World time clock: No
  • External thermometer: No
  • External reed switch sensor: No
  • External flood sensor:No
  • Water leakage: No
  • Alarm sirene: No

SOFTWARE:

Number of ready business cases: 10+

  • Full IoT platform provided with trial period:  Yes
  • Any IoT platform support: Yes
  • Programming of the device behaviour: Through web platform
  • Automation and workflow support: Yes
  • Custom firmware: Yes

RADIO PERFORMANCE:

  • Supported radio zones: All zones
  • Multizone: Yes
  • Monarch support: Yes
  • Sigfox Ready Class: Class 0 – Best
  • Sigfox IoT agency designed and tuned antenna: Yes
  • Support of 1 frame sending: Yes
  • Support of 600 bps encoding: Yes
  • Legal support of 2592 messages a day:  Yes
